| Part Number/Catalog No. |
1756-EN2F |
| Brand |
Allen-Bradley |
| Communication Port: |
One (1) Ethernet; One (1) USB |
| Ethernet Data Transfer speed: |
10 /100 Mbps |
| USB Data Transfer rate: |
12 Mbps |
| Mounting: |
Any 1756 Chassis |
| Backplane current: |
1.2 A at 5.1 VDC; 3 mA at 24VDC |
| Power Dissipation: |
6.2 W |
| Slot width |
1 |
| Chassis |
1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 |
| Power supply, standard |
1756-PA72, 1756-PA75, 1756-PB72, 1756-PB75, 1756- PC75, 1756-PH75 |
| Power supply, redundant |
1756-PA75R, 1756-PB75R, 1756-PSCA2 |
| Series |
ControlLogix |
| Module Type |
Ethernet Communication Module |
| TCP Connections |
128 |
| CIP Connections |
256 |
| Maximum Multicast Tags |
32 |
| Enclosure |
Open |
| Ethernet-IP Communication Rate |
10-1000 Megabites per second |
| Current Draw (5.1 Volts) |
1.2 Amps |
| Current Draw (24 Volts) |
3 milliamps |
| Voltage |
5.1 Volts DC |
| Current Rating |
1.2 Amps |
