24-Port Copper Managed Switch
P/N: P0973JM
The 24-Port Copper managed switch features:
24-ports of 100Base-TX
Two fixed RJ-45 10/100/1000 ports, configurablefor uplink
Two 1000Base-X uplink Gigabit (SFP) ports
Full duplex operation
Supports VLAN configurations
Monitoring and configuration tasks via local console port, or any SNMP/RMON based management application.
Port mirroring technology and diagnostics that allow local network traffic to be redirected to an external probe for detailed analysis
Compliance with industry standards, including IEEE 802.3u Fast Ethernet, 802.1w Rapid Spanning Tree Protocol (RSTP)
Optional redundant power supply
Shelf, desk, or 19-inch rack mounting.
INTRODUCTION
The 24-Port Copper managed switch (P0973JM) provides twenty-four 100Base-TX ports with RJ-45 connectors, two fixed 10/100/1000 stacking / uplink (ISL) ports and two 1000Base-X uplink (ISL) Gigabit (SFP) ports.
The two 1000Base-X uplink (ISL) Gigabit (SFP) ports can be populated with MGBIC uplink (ISL) connector modules listed.
The switch allows high-performance, full-featured layer-2 Ethernet switching in small to medium-sized network applications, as well as high-performance direct end-station connectivity.
| MAXIMUM POWER CONSUMPTION |
| 31 Watts |
| MAXIMUM HEAT DISSIPATION |
| 105 BTUs/Hr |
| MAXIMUM CURRENT |
| 0.5 A at 110 V ac, 0.47 A at 220 V ac |
| Operating Conditions TEMPERATURE |
| 0 to +50°C (32 to +122°F) |
| RELATIVE HUMIDITY |
| 5 to 95% (noncondensing) |
| Storage Conditions TEMPERATURE |
| -40 to +70°C (-40 to +158°F) |
| RELATIVE HUMIDITY |
| 5 to 95% (noncondensing) |
| Mounting | |
| Desk or Enclosure – 48.3 cm (19-inch) equipment rack,1U high | |
| Dimensions – Nominal | |
| HEIGHT | 4.4 cm (1.7 in) |
| WIDTH | 44.1 cm (17.36 in) |
| DEPTH | 36.85 cm (14.5 in) |
| Mass – Approximate | 2.61 kg (5.8 lb) |
| Cable Connectors | |
| SWITCH PORTS | RJ-45 |
| UPLINK PORTS | RJ-45 copper and LC fiber |
| Vibration | Vibration – IEC 68-2-36, IEC 68-2-6 |
| Shock – IEC 68-2-29 | |
| Drop – IEC 68-2-32 |
