| Range of Product | Altivar Process ATV600 |
|---|---|
| Product Specific Application | Process and utilities |
| Product or Component Type | Variable speed drive |
| Variant | Standard version |
| Device short name | ATV630 |
| Mounting Mode | Wall mount |
| Communication Port Protocol | Modbus TCP Ethernet Modbus serial |
| [Us] rated supply voltage | 380…480 V – 15…10 % |
| [Us] rated supply voltage | 380…480 V |
| Relative symmetric mains voltage tolerance | 10 % |
| Relative symmetric network frequency tolerance | 5 % |
| Nominal output current | 23.5 A |
| IP degree of protection | IP21 |
| Product destination | Asynchronous motors Synchronous motors |
| EMC filter | Integrated 164.04 ft (50 m) IEC 61800-3 category C2 Integrated 492.1 ft (150 m) IEC 61800-3 category C3 |
| IP degree of protection | IP21IEC 61800-5-1 IP21IEC 60529 |
| Degree of protection | UL type 1 UL 508C |
| type of cooling | Forced convection |
| Supply frequency | 50…60 Hz – 5…5 % |
| Motor power kW | 11 kW normal duty) 7.5 kW heavy duty) |
| Maximum Horse Power Rating | 15 hp normal duty 10 hp heavy duty |
| Line current | 19.8 A 380 V normal duty) 17 A 480 V normal duty) 14.1 A 380 V heavy duty) 12.5 A 480 V heavy duty) |
| Continuous output current | 23.5 A 4 kHz normal duty 16.5 A 4 kHz heavy duty |
| Speed drive output frequency | 0.1…500 Hz |
