6AV7885-5AM10-7GA8
SIMATIC HMI IPC 577C PCI slot, 4 USB (back)+1 USB (front), Ethernet (10/100/1000), 19″ touch display ; Core 2 Duo 1.86 GHz, PROFINET (IRT); 1x 1GBit 1 GB -RAM, DDR3; 2nd mass storage: Not equipped 1st mass storage (Operating system optional): 80 GB Solid-State Drive SATA (standard) Windows 7 Ultimate MUI pre-installed; (only possible with HD or SSD) without expansion (software) 24 V DC power supply
| Product | |
| Article Number (Market Facing Number) | 6AV7885-5AM10-7GA8 |
| Product Description | SIMATIC HMI IPC 577C PCI slot, 4 USB (back)+1 USB (front), Ethernet (10/100/1000), 19″ touch display ; Core 2 Duo 1.86 GHz, PROFINET (IRT); 1x 1GBit 1 GB -RAM, DDR3; 2nd mass storage: Not equipped 1st mass storage (Operating system optional): 80 GB Solid-State Drive SATA (standard) Windows 7 Ultimate MUI pre-installed; (only possible with HD or SSD) without expansion (software) 24 V DC power supply |
| Product family | SIMATIC HMI IPC 577C |
| Size | 19″ touch display |
| Processor type/CPU | Core 2 Duo 1.86 GHz |
| Memory capacity | 1 GB |
| Harddisk | 80 GB |
| Operating system/OS | Windows 7 Ultimate MUI pre-installed |
| Communication Interface | PROFINET (IRT) |
| Network Interface | Ethernet (10/100/1000) |
| Other interface | 4 USB (back)+1 USB (front) |
| Power supply | 24 V DC |
| Warranty | 1 year |
| Net Weight (kg) | 15,000 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84714100 |
| LKZ_FDB/ CatalogID | ST80E |
| Product Group | 4386 |
| Group Code | R133 |
