6ES7647-6BH52-0AX0
***no longer available*** SIMATIC Box PC 627B; graphics onboard, 128 MB Shared memory; 2×10/100/1000 Mbit/s Ethernet RJ45; 4xUSB V2.0 (high current); 1x serial (COM1) RAID controller onboard; CompactFlash Drive No. 1 front-side (without CF); Watchdog, temp./fan monitoring Core 2 Duo T7400 (2.16 GHz, 4 MB SLC; 667 MHz FSB); PROFIBUS/MPI; 2 MB buffered SRAM 4 GB DDR2 667 SODIMM AC 110/230V industrial power supply unit with NAMUR; power supply cable CH 2x PCI free 160 GB HDD SATA without operating system without expansion (software)
| Product | |
| Article Number (Market Facing Number) | 6ES7647-6BH52-0AX0 |
| Product Description | ***no longer available*** SIMATIC Box PC 627B; graphics onboard, 128 MB Shared memory; 2×10/100/1000 Mbit/s Ethernet RJ45; 4xUSB V2.0 (high current); 1x serial (COM1) RAID controller onboard; CompactFlash Drive No. 1 front-side (without CF); Watchdog, temp./fan monitoring Core 2 Duo T7400 (2.16 GHz, 4 MB SLC; 667 MHz FSB); PROFIBUS/MPI; 2 MB buffered SRAM 4 GB DDR2 667 SODIMM AC 110/230V industrial power supply unit with NAMUR; power supply cable CH 2x PCI free 160 GB HDD SATA without operating system without expansion (software) |
| Series name | SIMATIC Box PC 627B |
| graphics onboard | |
| Processor type/CPU | Core 2 Duo T7400 |
| memory capacity | 128 MB Shared memory |
| harddisk | 160 GB HDD SATA |
| 2 MB buffered SRAM 4 GB DDR2 667 SODIMM | |
| operating system/OS | without |
| Network Interface | 2×10/100/1000 Mbit/s Ethernet RJ45 |
| touchpad type | —— |
| Shell type | Aluminum shell |
| Communication Interface | —— |
| Other interface | 4xUSB V2.0 |
| power supply | AC 110/230V |
| programming software | without |
| Warranty | 1 YEAR |
| Net Weight (kg) | 6,850 Kg |
| Packaging Dimension | Not available |
| Country of origin | Germany |
| Quantity Unit | 1 Piece |
| Packaging Quantity | 1 |
| Additional Product Information | |
| EAN | Not available |
| UPC | Not available |
| Commodity Code | 84715000 |
| LKZ_FDB/ CatalogID | IC10-E |
| Product Group | 4342 |
| Group Code | R115 |
